  • UtiliTrak® SW Series Channel and Plates
UtiliTrak® is an ideal choice for running two systems in parallel, where one slide uses DualVee® guide wheels and the other uses MadeWell® crowned rollers. Because precise parallelism is difficult to achieve, it is not uncommon for mounting surfaces to be slightly out of parallel. UtiliTrak®'s design compensates for mounting errors, and does not require absolute parallelism for accurate operation. The DualVee® guide wheel plate assembly and vee channel serves as the motion side, while the MadeWell® crowned roller and open channel side allows for parallel misalignment.

SW Series includes carbon steel guide wheels running on a hardened bearing grade carbon steel linear track channel for larger loads and smooth operation.

SW Series UtiliTrak® is ideal for medium to heavy duty transport applications, and offers high speeds, excellent load capacity, smooth antifriction operation, and debris tolerance.

  • Steel DualVee® wheels and MadeWell® crown rollers available shielded or sealed
  • Loads to 14,040N
  • Speeds to 5.5 m/s
  • Acceleration to 5 g's
  • 3, 4 or 5-wheel plate assemblies available
  • Available in sizes 1, 2, and 3
1 - 25 of 33 | Results Per Page | View | Unit of Measure
1 2
Request Information Compare Items

Item #

Item Name

Model

Bearing Type

Type

Size

Speed

Acceleration

N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 3-Wheel, Carbon, Shielded N/A UT0WPA N/A Bearing Block N/A Shielded N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 4-Wheel, Carbon, Shielded N/A UT0WPA-4A N/A Bearing Block N/A Shielded N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 5-Wheel, Carbon, Shielded N/A UT0WPA-5A N/A Bearing Block N/A Shielded N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 3-Wheel, Carbon, Sealed N/A UT0WPAX N/A Bearing Block N/A Sealed N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 4-Wheel, Carbon, Sealed N/A UT0WPAX-4A N/A Bearing Block N/A Sealed N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 0, 90 Degree Vee, 5-Wheel, Carbon, Sealed N/A UT0WPAX-5A N/A Bearing Block N/A Sealed N/A 0 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 3-Wheel, Carbon, Shielded N/A UT1WPA N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 4-Wheel, Carbon, Shielded N/A UT1WPA-4A N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 5-Wheel, Carbon, Shielded N/A UT1WPA-5A N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 3-Wheel, Carbon, Sealed N/A UT1WPAX N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 4-Wheel, Carbon, Sealed N/A UT1WPAX-4A N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, 90 Degree Vee, 5-Wheel, Carbon, Sealed N/A UT1WPAX-5A N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 3-Wheel, Carbon, Shielded N/A UT1WPAR N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 4-Wheel, Carbon, Shielded N/A UT1WPAR-4A N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 5-Wheel, Carbon, Shielded N/A UT1WPAR-5A N/A Bearing Block N/A Shielded N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 3-Wheel, Carbon, Sealed N/A UT1WPAXR N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 4-Wheel, Carbon, Sealed N/A UT1WPAXR-4A N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 1, Crown Roller, 5-Wheel, Carbon, Sealed N/A UT1WPAXR-5A N/A Bearing Block N/A Sealed N/A 1 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, 90 Degree Vee, 3-Wheel, Carbon, Sealed/Shielded N/A UT2WPAXS N/A Bearing Block N/A Seal/Shield N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, 90 Degree Vee, 4-Wheel, Carbon, Sealed/Shielded N/A UT2WPAXS-4A N/A Bearing Block N/A Seal/Shield N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, 90 Degree Vee, 5-Wheel, Carbon, Sealed/Shielded N/A UT2WPAXS-5A N/A Bearing Block N/A Seal/Shield N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, Crown Roller, 3-Wheel, Carbon, Shielded N/A UT2WPAR N/A Bearing Block N/A Shielded N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, Crown Roller, 4-Wheel, Carbon, Shielded N/A UT2WPAR-4A N/A Bearing Block N/A Shielded N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, Crown Roller, 5-Wheel, Carbon, Shielded N/A UT2WPAR-5A N/A Bearing Block N/A Shielded N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
N/A UtiliTrak® SW Series Wheel Plate, Size 2, Crown Roller, 3-Wheel, Carbon, Sealed N/A UT2WPAXR N/A Bearing Block N/A Sealed N/A 2 N/A Up to 5.5 m/s N/A Up to 5 g
